Aluminium alloy aerial lift platform is mainly made up of high strength high quality aluminium alloy materials.This
lift platform uses mast column to support the working platform.it is designed for earial works.
GTWY Aluminium Alloy Aerial Lift Platform
Product Name:GTWY Aluminium Alloy Aerial Lift Platform
Product Detail
| Model | GTWY601 | GTWY801 | GTWY1001 |
| Platform height(mm) | 6000 | 8000 | 10000 |
| Working height(mm) | 8000 | 10000 | 12000 |
| Load capacity(kg) | 150 | 125 | 125 |
| Platform size(mm) | 630×640 | 630×640 | 630×640 |
| Power voltage(V) | DC12V/AC220V | DC12V/AC220V | DC12V/AC220V |
| Motor power(Kw) | 0.75 | 0.75 | 0.75 |
| Overall size(mm) | 1420×820×1920 | 1420×820×2040 | 1420×820×20400 |
| Up/Down speed(M/s) | 38/35 | 44/38 | 46/40 |
| Self weight AC/DC(kg) | 415/450 | 450/485 | 490/525 |
